- Wiring Harness
- Custom Specialized wiring harness
- Charger
- Custom charger, 42V4A w/ Rosenberger plug, 100-240V
- Battery
- Specialized M3-700, Integrated battery, 700Wh
- UI/Remote
- Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
- Motor
- Specialized 2.2 Custom Rx Trail Tuned Motor, 90Nm Torque, 565W Power
- Seat Binder
- Alloy, 38.6
- Frame
- FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot
- Fork
- FOX FLOAT 38 Performance Elite 29, Grip2 damper, 44mm offset, HSC, LSC, HSR, LSR, 110x15mm, 1.5" tapered steerer, 160mm travel
- Rear Shock
- S1: Fox Float DPS Performance, S2-S6: FOX FLOAT X2 Performance, LSC, LSR, 2-position lever
- Rear Brake
- SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm
- Front Brake
- SRAM Code RS, 4-piston caliper, hydraulic disc, S/M: 200mm, L/XL: 220mm
- Crankset
- Praxis Forged/Custom Offset/ISIS Spindle Interface, 160mm
- Chain
- SRAM GX Eagle, 12-speed
- Chainrings
- SRAM X-Sync Eagle, 104 BCD, 32T, steel
- Shift Levers
- SRAM XO1 Eagle trigger, 12-speed, single click
- Rear Derailleur
- Sram X01 Eagle, 12-speed
- Cassette
- Sram XG-1275, 12-speed, 10-52t
- Front Tire
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
- Rear Tire
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
- Inner Tubes
- Standard, Presta Valve
- Rear Wheel
- Traverse 27.5
- Front Wheel
- Traverse 29
- Stem
- Alloy Trail Stem, 35mm bar bore
- Saddle
- Bridge Comp, Hollow Cr-mo rails, 155/143mm
- Grips
- Deity, Knuckleduster, Black
- Handlebars
- Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp
- SeatPost
- X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm
- SWAT
- SWAT CC steerer tube integrated tool with chain tool and link
Geometry
S1 | S2 | S3 | S4 | S5 | S6 | |
---|---|---|---|---|---|---|
Crank Length | 160 | 160 | 160 | 160 | 160 | 160 |
Handlebar Width | 780 | 780 | 780 | 780 | 780 | 780 |
Stem Length | 40 | 40 | 50 | 50 | 50 | 50 |
Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
Seatpost Length | 100 | 125 | 150 | 170 | 170 | 190 |
Stack | 605 | 617 | 626 | 635 | 644 | 653 |
Reach | 412 | 432 | 452 | 477 | 502 | 532 |
Headtube Length | 105 | 105 | 115 | 125 | 135 | 145 |
Headtube Angle | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
BB Height | 352 | 350 | 350 | 350 | 350 | 350 |
BB Drop | 25 | 27 | 27 | 27 | 27 | 27 |
Trail | 130 | 130 | 130 | 130 | 130 | 130 |
Fork Length (full) | 557 | 567 | 567 | 567 | 567 | 567 |
Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 | 44 |
Front Center | 738 | 760 | 784 | 814 | 843 | 878 |
Chainstay Length | 442 | 442 | 442 | 442 | 442 | 442 |
Wheelbase | 1179 | 1200 | 1225 | 1255 | 1284 | 1318 |
Bike Standover Height | 752 | 776 | 783 | 787 | 788 | 790 |
Seat Tube Length | 380 | 390 | 405 | 425 | 445 | 465 |
Seat Tube Angle | 78 | 77.2 | 76.7 | 76.2 | 76.2 | 76.2 |
Max Seatpost Insertion | 210 | 220 | 240 | 255 | 275 | 295 |
Min Seatpost Insertion | 80 | 80 | 80 | 80 | 80 | 80 |
